| 产品料号 | 额定电流 | 额定电压 | 分断能力 | 安装孔尺寸 | 安装孔数量 | * |
* |
材质 |
|---|---|---|---|---|---|---|---|---|
| ANS-36-030-A2 | 30A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-040-A2 | 40A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-050-A2 | 50A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-060-A2 | 60A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-070-A2 | 70A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-080-A2 | 80A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-100-A2 | 100A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-125-A2 | 125A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-150-A2 | 150A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-175-A2 | 175A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-200-A2 | 200A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Tin-plated Copper |
| ANS-36-030-A1 | 30A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-040-A1 | 40A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-050-A1 | 50A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-060-A1 | 60A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-070-A1 | 70A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-080-A1 | 80A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-100-A1 | 100A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-125-A1 | 125A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-150-A1 | 150A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-175-A1 | 175A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-200-A1 | 200A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Tin-plated Copper |
| ANS-36-030-B2 | 30A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-040-B2 | 40A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-050-B2 | 50A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-060-B2 | 60A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-070-B2 | 70A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-080-B2 | 80A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-100-B2 | 100A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-125-B2 | 125A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-150-B2 | 150A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-175-B2 | 175A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-200-B2 | 200A | 70V | 1000A@70V | M6 | 2 | ● | ● | PA, Bare Brass |
| ANS-36-030-B1 | 30A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-040-B1 | 40A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-050-B1 | 50A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-060-B1 | 60A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-070-B1 | 70A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-080-B1 | 80A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-100-B1 | 100A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-125-B1 | 125A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-150-B1 | 150A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-175-B1 | 175A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| ANS-36-200-B1 | 200A | 70V | 1000A@70V | M6 | 1 | ● | ● | PA, Bare Brass |
| 厂商 | 料号 |
|---|---|
| Littelfuse | MIDI / 4998XXX |
| PEC | SBFW-L48V-M6L |
